octopus
camera

specialist sensor options

8k, global shutter, full frame, b/w, full spectrum

powered by linux

programmable, upgradable

compact

110 x 110 x 130mm, less than 1kg

upgradeable open-platform hardware

The OCTOPUS CAMERA uses the compact Intel® NUC as the processing board. Components can be removed and upgraded including the board itself when newer boards are available.

interchangeable specialist image sensors

XIMEA provide a range of high-performance imaging modules which can be interchanged allowing the OCTOPUS CAMERA to have a fully upgradable image sensor.

Specialist sensors available include specifications such as full-frame 35mm, Global Shutter, native Monochrome and more.

open standard formats and technologies

Out of the box, the OCTOPUS CAMERA records losslessly compressed 4K RAW into CinemaDNG format. For longer record times, the camera also records high bitrate 10-bit HEVC.

Additional recording formats can be added with our SDK through Libavcodec or 3rd party libraries.

SPECIFICATIONS

8K
FULL FRAME
CMV50000
7920 x 6004
GLOBAL Shutter
Up to 14 Stops DR
Monochrome / Colour
Removable Active Canon EF Mount

Compressed RAW /
10-bit Compressed /
12-bit Lossless RAW (via Thunderbolt™ 3)
8K up to 42fps (TBC)
4K up to 60fps (TBC)


14-bit Lossless RAW
4K up to 30fps
3K up to 60fps
2K up to 110fps

4K
4/3 Inch
Sony IMX253
4112 x 3008
GLOBAL Shutter
12.5 Stops DR
Monochrome / Colour
Removable Micro Four Thirds Mount

Compressed RAW /
10-bit Compressed /
12-bit Lossless RAW (via USB-C)
4K up to 70fps
3K up to 120fps
2K up to 240fps

12-bit Lossless RAW
4K up to 30fps
3K up to 60fps
2K up to 120fps


Internal CFast 2.0 recording
SATA III based CFast 2.0 for write speeds over 400MB/s

External Thunderbolt™ 3 SSD recording
Thunderbolt™ 3 USB-C port for up to 5000MB/s bandwidth

Mainboard - Intel® NUC 8V7PNB
Intel® Core™ i7-8665U
16GB DDR4 RAM (Upgradeable to 64GB)
SATA III 6GB/s, 4x PCI-e Gen 3.0
3x USB3 Gen 2, 2x HDMI 2.0 ports, Thunderbolt™ 3 USB-C

Additional IO
3G-SDI In / Out
Genlock reference input

Body
110 x 110 x 130mm, 900 grams
CNC Aluminium in gloss white finish
Designed and assembled in London, UK

COMING 2021
